• working principle:

    The drive roller of the belt conveyor is driven by the motor through a speed reducer which is dragged by the friction between the drive roller and the conveyor belt. The driving rollers are generally installed at the discharge end to increase the traction and facilitate dragging. The material is fed from the feeding end, falls on the rotating conveyor belt, and is transported to the discharge end by the friction belt of the conveyor belt. Belt conveyor designed by Juli: The maximum capacity is up to 20000t/h, the widest bandwidth is up to 2400mm, and the longest conveying distance is up to 10KM.



    Main Technical Parameters of DT Belt Conveyor

    Belt Width

    (mm)

    Repose

    Angle

    Belt speed(m/s)

    2.0

    2.5

    3.15

    4.0

    5.0

    6.3

    Carrying Capacity(t/h)

    800

    10°-20°

    380-550

    480-680

    600-850

    ---

    ---

    ---

    1000

    630-880

    790-1110

    1000-1400

    1200-1700

    ---

    ---

    1200

    900-1300

    1150-1600

    1450-2050

    1850-2600

    2300-3200

    ---

    1400

    1250-1800

    1580-2250

    2000-2800

    2550-3600

    2190-4500

    ---

    1600

    1700-2350

    2100-2950

    2650-3850

    3400-4750

    4250-5950

    ---

    1800

    2150-3050

    2700-3800

    3440-4840

    4350-6100

    5450-7650

    6800-9600

    2000

    ---



    4380-6050

    5480-7680

    6850-9600

    8700-12000

    2200

    ---



    5300-7300

    6700-9300

    8400-11700

    10600-14600

    2400

    ---



    6300-8600

    7900-11000

    9900-13800

    12600-17200

    Note:The carrying capacity in the table is calculated on the basis of 1t/m³ volumetric weight, horizontal conveyance, and idler troughing angle at 30°.
